ForSerialNos.
720,000&Higher
LAZERZ®
LZ27KC604MODELONLY
PlaceModelNo.andSerialNo.
LabelHere(IncludedintheLiterature
Pack)orFillinBelow
DatePurchased
EngineModelNo.andSpec.No.
ModelNo.EngineSerialNo.(E/No)
SerialNo.
PartNo.4500-246Rev.A

Table of Contents

Questions and Answers

  • P
    Paul DuranAug 14, 2025
    What to do if Exmark LAZER Z LZ27KC604 Lawn Mower starter does not crank?
    • C
      Chelsey RiveraAug 14, 2025
      If the starter on your Exmark Lawn Mower doesn't crank, several issues could be the cause. First, ensure the PTO is disengaged and the parking brake is set. Also, check that the drive levers are in the neutral lock position. A low battery charge can also prevent the starter from cranking, so charge the battery. Inspect all electrical connections for corrosion or looseness; clean and reconnect them as needed. Lastly, a blown fuse could be the culprit, so replace it if necessary. If these steps don't resolve the issue, the relay or switch may be defective, and you should contact an Authorized Service Dealer.
  • L
    Laura ChambersAug 17, 2025
    Why Exmark LAZER Z LZ27KC604 engine will not start?
    • T
      Tonya MaldonadoAug 18, 2025
      If your Exmark Lawn Mower engine won't start, starts hard, or fails to keep running, several factors could be responsible. Make sure the fuel tank isn't empty and the fuel shutoff valve is open. Check the oil level in the crankcase and add oil if it's low. Ensure the throttle and choke are in the correct positions. Other potential causes include a dirty fuel filter (replace it), a dirty air cleaner (clean or replace it), or a faulty spark plug (clean, adjust, or replace it). Also, be sure the spark plug wire is connected and the seat switch is properly adjusted. Inspect electrical connections for corrosion or looseness, cleaning and reconnecting as necessary. For issues like dirt, water, or stale fuel in the fuel system, or a defective relay or switch, contact an Authorized Service Dealer.
  • C
    Carlos ParkerAug 21, 2025
    What to do if Exmark LAZER Z LZ27KC604 engine looses power?
    • B
      Becky MedinaAug 21, 2025
      If your Exmark Lawn Mower engine loses power, consider these possible causes: The engine load might be excessive, so reduce the ground speed. A dirty air cleaner can also cause power loss, so clean or replace the air cleaner element. Check the oil level in the crankcase and add oil if needed. Make sure the cooling fins and air passages for the engine are free from obstructions. Additionally, a plugged vent hole in the fuel cap or a dirty fuel filter can restrict fuel flow; clean or replace these parts as necessary. For issues like dirt, water, or stale fuel in the fuel system, contact an Authorized Service Dealer.
  • A
    Ashley GuzmanAug 25, 2025
    How to fix uneven cutting height on Exmark LAZER Z LZ27KC604 Lawn Mower?
    • E
      emily49Aug 25, 2025
      To fix an uneven cutting height on your Exmark Lawn Mower, consider these steps: Start by sharpening the blade(s). If the cutting blade(s) is/are bent, install new cutting blade(s). Ensure the mower deck is level from side-to-side and front-to-rear. Clean the underside of the mower to remove any debris. Also, verify that the tire pressure in the drive tires is correct. If the tips of adjacent blades are at an uneven cutting height, replace blades, spindles and (or) check for damage to mower deck. For a bent blade spindle, contact an Authorized Service Dealer.
  • T
    Tina BeckerAug 27, 2025
    What to do if Exmark LAZER Z LZ27KC604 blades do not rotate?
    • M
      Manuel JacksonAug 27, 2025
      If the blades on your Exmark Lawn Mower do not rotate, several issues could be the cause. First, check the belt tension if the drive belt is worn, loose, or broken. If the drive belt is off the pulley, install the drive belt and check the adjusting shafts and belt guides for the correct position. Install a new deck belt if the current one is worn, loose, or broken. If the deck belt is off the pulley, install the deck pulley and check the idler pulley, idler arm, and spring for correct position and function. Replace the spring if it is broken or missing.
  • L
    Lindsay EstradaAug 31, 2025
    Why does my Exmark LAZER Z LZ27KC604 overheat?
    • B
      Barbara WangAug 31, 2025
      If your Exmark Lawn Mower engine overheats, the following factors may be the reason: The engine load might be excessive, so reduce the ground speed. Check the oil level in the crankcase and add oil if it's low. Also, ensure that the cooling fins and air passages for the engine are free of any obstructions.
  • T
    tyler39Sep 3, 2025
    What to do if Exmark LAZER Z LZ27KC604 pulls left or right?
    • M
      Mckenzie RiggsSep 3, 2025
      If your Exmark Lawn Mower pulls to the left or right even when the levers are fully forward, it could be due to several reasons. First, the tracking may need adjustment. Also, check and adjust the tire pressure in the drive tires to ensure they are correct. Finally, the reverse indicator and motion control linkage may require adjustment.
  • S
    Samantha WeissSep 7, 2025
    What to do if Exmark LAZER Z LZ27KC604 Lawn Mower machine does not drive?
    • S
      Shannon JohnsonSep 7, 2025
      If your Exmark Lawn Mower doesn't drive, several potential issues could be the cause. Ensure the bypass valve is closed tightly. Inspect the drive or pump belt for wear, looseness, or breakage, and change the belt if necessary. Also, check if the drive or pump belt is off a pulley, and change the belt. A broken or missing idler spring can also prevent the machine from driving, so replace the spring. Finally, check the hydraulic fluid level; if it's low, add hydraulic fluid to the reservoir, or if it's too hot, allow it to cool down.
  • J
    Jose WilliamsSep 10, 2025
    Why is my Exmark LAZER Z LZ27KC604 having abnormal vibration?
    • K
      Kristin DickersonSep 10, 2025
      If your Exmark Lawn Mower is experiencing abnormal vibration, here are some possible causes: * The cutting blade(s) might be bent or unbalanced, so install new cutting blade(s). * Check if the blade mounting bolt is loose and tighten it. * Also, inspect the engine mounting bolts and tighten them if they are loose. * A loose engine pulley, idler pulley, or blade pulley can also cause vibration, so tighten the appropriate pulley. For a damaged engine pulley or a bent blade spindle, contact an Authorized Service Dealer.

Summary

Introduction

Safety

Safety Alert Symbol

Identifies important safety messages to avoid accidents. Explains DANGER, WARNING, and CAUTION.

Safe Operating Practices

Covers training, preparation, and general rules for safe operation of the mower.

Slope Operation

Provides precautions and guidelines for safely operating the mower on slopes.

Using the Rollover Protection System (ROPS)

Instructions for proper use of the ROPS, including warnings and safety measures.

Maintenance and Storage

Specifications

Engine

Details engine specifications including RPM and owner's manual reference.

Operator Controls

Describes the function of steering, motion control, PTO, and deck adjustment levers.

Hydrostatic Ground Drive System

Specifies hydrostatic pumps, wheel motors, oil type, capacity, and speeds.

Product Overview

Torque Requirements

Lists torque specifications for various bolts and nuts used in assembly.

Operation

Controls

Details motion control levers, choke, throttle, brake, ignition switch, and gauges.

Pre-Start Procedures

Guides on filling fuel tanks, checking controls, and performing pre-operation checks.

Starting the Engine

Step-by-step instructions for starting the mower engine safely.

Engaging the PTO

Instructions on how to safely engage the Power Take-Off (PTO) for blade operation.

Disengaging the PTO

Instructions on how to safely disengage the Power Take-Off (PTO).

Stopping the Engine

Procedure for safely shutting down the mower engine.

Driving the Machine

Guidelines for safe forward, reverse, and turning maneuvers.

Adjusting the Cutting Height

Steps for adjusting the mower deck cutting height.

Maintenance

Recommended Maintenance Schedule(s)

Outlines maintenance tasks and intervals for the mower.

Periodic Maintenance

Covers routine checks, fluid levels, and basic servicing procedures.

Adjustments

Troubleshooting

Exmark LAZER Z LZ27KC604 Specifications

General IconGeneral
SeriesLazer Z
Deck TypeFabricated
Product TypeZero-Turn Lawn Mower
EngineKohler Command Pro
Cutting Width60 inches
Turning RadiusZero
