6
FIGURE 1
• Progressively greater care is needed as the slope increases.
• Always avoid sudden starting or stopping on a slope. If tires lose traction,
disengage the blades and proceed slowly off the slope.
• Avoid sudden starts when mowing uphill. Mower may tip backwards.
• Be aware that loss of traction may occur going downhill. Weight transfer to
the front wheels may cause drive wheels to slip and cause loss of braking
and steering.
• Watch for ditches, holes, rocks, dips, and rises that change the operating
angle, as rough terrain could overturn the machine.
• Remove or mark obstacles such as rocks, tree limbs, etc. from the mowing
area. Tall grass can hide obstacles.
• Use extreme care with grass catchers or attachments. These can change the
stability of the machine and cause loss of control.
• Follow the manufacturer’s recommendations for wheel weights or
counterweights to improve stability.
1.4.5 A Rollover Protection System (roll bar) is installed on the unit.
WARNING
POTENTIAL HAZARD
♦ There is no rollover protection when the
roll bar is down.
WHAT CAN HAPPEN
♦ Wheels dropping over edges, ditches,
steep banks, or water can cause
rollovers, which may result in serious
injury, death or drowning.
HOW TO AVOID THE HAZARD
♦ Keep the roll bar in the raised and locked
position and use seat belt.
♦ Lower the roll bar only when absolutely
necessary.
♦ Do not wear seat belt when the roll bar is
down.
♦ Drive slowly and carefully.
♦ Raise the roll bar as soon as clearance
permits.
• Be certain that the seat belt can be released quickly if the machine is driven or
rolls into ponds of water.
