Maintenance
g035850
Figure69
1.Adjustingscrew
3.Setgapto3/4–7/8inch
(19–22mm)
2.Bracket
9.Settheheight-of-cutlevertothe3inch(76mm)
position.Placetwo“B”thickblocks(seeBlock
HeightandRakeTable)undertherearedgeofthe
cuttingdeckskirt;oneoneachsideofthecutting
deck.Placetwo“ A”thickblocksundereachside
ofthefrontedgeofthedeck,butnotunderthe
anti-scalprollerbrackets.
SandE-Series—BlockHeightandRakeTable
Deck
Size
FrontBlock
Height“ A”
RearBlock
Height“B”
Rake“R”
44,
48,
52,&
60
2.56inches
(6.5cm)
2.81inches
(7.1cm)
1/16–5/16inch
(1.6–7.9mm)
60R
2.63inches
(6.7cm)
2.63inches
(6.7cm)
0–1/8inch
(0–3.2mm)
X-Series—BlockHeightandRakeTable
Deck
Size
FrontBlock
Height“ A”
RearBlock
Height“B”
Rake“R”
48,
52,&
60
2.63inches
(6.7cm)
2.88inches
(7.3cm)
1/16–5/16inch
(1.6–7.9mm)
10.Carefullyrotatethebladessidetoside(Figure68).
11.Loosenthelevelingadjustlockingnuts(item1
Figure70)onallfourcornerssothatthedeckis
sittingsecurelyonallfourblocks.Makesurethat
theslackisremovedfromthedeckhangersand
thedeckliftfootleverispushedbackagainstthe
stop,thentightenthefourlevelingadjustlocking
nuts.
g035851
Figure70
1.Levelingadjustlocking
nuts
3.Deckhanger
2.Deckliftarm4.Chain
12.Recheckthatblockstjustsnuglyunderthedeck
skirt.Makesureallattachmentboltsaretight
13.Continuelevelingthedeckbycheckingthe
front-to-rearbladeslope;refertoAdjustingthe
BladeSlope.
14.Recheckbladesforlevelnessandrepeatdeck
levelingprocedureifnecessary.
15.For60InchDecksOnly:
A.Raisethedecktothetransport(5inch(12.7
cm)cuttingheight)position.
B.Reinstalltheliftassistspringadjustingscrew
thatwasremovedinstep8.
67
