Exmark Radius S Series User Manual

Maintenance
1.Drivethemachineontoalevelsurface.
2.Disengagethebladecontrolswitch(PTO),move
themotioncontrolleverstotheneutrallocked
positionandsettheparkingbrake.
3.Stoptheengine,waitforallmovingpartstostop,
andremovethekey.
4.Setupthemachinetobepushedbyhand(see
DriveWheelReleaseValvesintheOperation
section).
5.Raisethebackofthemachineupandsupportthe
machinewithjackstands.
6.Engage/disengagethebrakeandcheckeachdrive
tiretomakesureeachbrakeengages/disengages.
7.Ifadjustmentisnecessary,disengagethepark
brake.Removecotterpinfromthebrakelinkage
shaft(seeFigure72).
g035879
Figure72
1.Cotterpin3.Brakelinkageshaft
2.Parkingbrake
8.CheckbothspringlengthsasshowninFigure73.
Ifadjustmentisnecessary,turnthetopnut
clockwisetoshortenandcounterclockwiseto
lengthen.
g036100
Figure73
1.Topnut
3.1.75inches(44mm)
2.Spring
9.Pushtheparkingbrakeleverallthewayforward
anddown.Rotatethebrakelinkageshaftuntilthe
endalignswithholeinlever.
•Shortenthelinkagebyturningitclockwise.
•Lengthenthelinkagebyturningit
counterclockwise.
Insertthebrakelinkageshaftintoparkingbrake
holeandsecurewiththecotterpin.Repeatstep6
andreadjustifnecessary.
10.Whenadjustmentiscomplete,removethejack
standsorequivalentsupportandlowerthe
machine.
11.Placethemachineintothe“operating”position.
RefertotheDriveWheelReleaseValvessection
inOperation.
MotionControlHandle
Adjustment
Adjustingtheheight:
69

Exmark Radius S Series Specifications

General

Engine Brand	Kawasaki
Cutting Width	52 inches
Transmission	Hydrostatic
Deck Construction	Fabricated
Deck Material	10-gauge steel
Engine Type	4-cycle
Drive Type	Rear-wheel drive
Speed	8 mph
Spindle Material	Aluminum
Deck Lift System	Foot-operated
