Exor JSmart 710 - Dimensions

15
MANUGENJSMART7xxW - Version 1.02
© 2019-2020 EXOR International S.p.A. - Subject to change without notice
4.1 Dimensions
4 Technical Data
MODEL A B C
D
JSmart707 131.6mm/5.18” 195.2mm/7.68” 16,5mm/0.64” 17mm/0.66”
MODEL A B C
D
JSmart710 183.1mm/7.20” 264.5mm/10.41”
16,5mm/0.64” 17mm/0.66”
