28
Taking measurements
Installing the S
TUD
1
Unscrew the
P
IN
from the sensor and place it in the lid stor-
age compartment of the carrying case.
2
Screw the
S
TUD
snugly into the hole on the front of the
sensor. You may need a small screwdriver for this
operation.
Selecting core diameter
You will need to specify the core diameter in order to get a cor-
rect reading, as this diameter is critical to the geometric correc-
tion that the KT-9 performs. You will be automatically
presented with the d: (
DIAMETER
) menu when the
C
ORE
mode is
selected from the A: (
ACCESS
) operating menu. This is shown in
Figure 4 on page 14.
The core diameters are specified in 1 centimetre increments
from
3
to
12
centimetres. A special value of 2.54 is used to
specify a
1
inch diameter core.
To select the core diameter:
1
Press the
L
EFT
button when the
C
ORE
mode is displayed
from the A: menu, i.e.
2
The first choice of the d: (
DIAMETER
) menu is displayed, e.g.
A:Cor
d:2.54
