C
ORE
mode
29
3
Press the
R
IGHT
button to toggle to the desired diameter. If
you accidently pass it, you will have to cycle all the way
around to the value again.
4
Press the
L
EFT
button to set the diameter.
5
Press the
L
EFT
button again to pass through the C: menu
and get back to the measurement mode.
Taking the reading
Please refer also to the flowchart shown in Figure 5 on page 20.
d: 4
1
You are ready to take a reading, if your
display shows either:
This example is illustrated with the
KT-9 set for the L
EFT
button.
2
Press the L
EFT
button to zero the instru-
ment while holding it at least 30 cm away
from any magnetically susceptible mate-
rial. The KT-9 will beep when the button
is pressed.
3
The display will show:
If the value is not 0, then you have old
data in memory that should be cleared.
Please refer to “Clearing the memory”
on page 37 for further instructions.
r:C x
L:C x
or
C: 0
