ZENITH
The minimum dimensions for the place of the machine must be 360 mm wide x
415 mm depth x 620 mm high.
Positionthemachineonaatandstablesurface,awayfromwaterandsourcesof
heat.
It should be located in a dry environment, since excessive humidity will affect the
machine negatively.
Donotcoverthemachinewithplasticlmorcloths.
Only connect the machine to a grounded power supply.
Check the correct voltage and frequency on the technical data plate.
Positioning
Electrical connection
Starting the grinder
MIN. 10 cm
Note:
Make sure that air is able to circulate behind the machine (minimum 10 cm).
i
Insert the container into its seat; positioning it so
that the hole lines up with the screw on the back
part of grinder.
Tighten the lock screw.
01
02
INSTALLATION
AND START-UP
