Exsys EX-1309-T - Hardware Layout and Connections; Device Layout; USB Connector Pinout

13
EX-1309-T English
3. Layout and Connections
3.1 Layout
USB A-Connector
3.2 Connections
USB A-Connector:
USB 2.0 A-Connector
Pin Signal Pin Signal
1 VCC 3 DATA+
2 DATA- 4 GND
S1: 1 x 5 Pin Serial
Terminal Block
Dipp-Switch to set the vari-
ous types of the transmission
