Extang Trifecta 2.0 - Detach Cab and Tail Rails; Tarp Install; Install Retaining Strip into Tail Rail; Install Retaining Strip into Cab Rail

Tarp Removal
Tarp Install
The nal step is to detach the cab rail and tail rail. The retaining strip does not slip out like the side rails.
They must be slid along the entire length of the tarp.
Begin with the tail rail and insert the retaining
strip into the rail. Continue to slide the rail
until it is centered in the tarp.
The Trifecta 2.0 badge is sewn in and marks
the rear corner.
Slide the retaining strip into the cab
rail, paying attention to center the
tarp. The two front buckles insert
outside of and around the tarp.
Check and remove any slivers or
burrs that may have come from the
retaining strip sliding along both the
cab and tail rails.
7
1
2 3
CAB END
TAIL END
