C-12 CRUSHER
DAILY MAINTENANCE SCHEDULE Cont.
Check service indicators on Air Cleaner. Regardless of condition of service indicator, remove
elements from air cleaner as shown below and clean them using compressed air.
(NOTE:- Service indicators are for showing when elements need to be replaced, not cleaned.)
Bleed diesel water trap.
Diesel Tap
2:- Unscrew nut to remove cover.
5:- Replace elements and rear
cover after cleaning.
4:- Remove inner element3:- Loosen nut & Remove outer
element
1:- Air cleaner inside of Power Unit
Securing nut
cover
Service indicator.
Check radiator water level & refill if necessary.
Radiator Cap
27
To Next Page
