C-12 CRUSHER
MAINTENANCE SCHEDULE - EVERY 1000Hrs
Every 1000 hours, the following maintenance must be carried out:-
i) Repeat 250 hr maintenance schedule.
ii) Change oil in vibrating feeder.
iii) Change diesel filters.
iv) Replace Toggle clamping & link arm ram bearings.
v) Change oil in tracks.
To drain oil from the track gearbox, drive the machine until either one of the drain
plugs is at the bottom of the gearbox. Remove drain plug and oil will drain out. Use a
suitable container to collect waste oil - disposing of waste oil must be done in a manner
that complies with any relevant legislation.
To refill track gearbox with oil, drive machine until either one of the drain plugs is at the top
- (See Photo). NOTE:- this will only be 1/4 turn of the track gearbox, DO NOT drive
machine any further until oil has been replaced in tracks. Remove both drain plugs as shown
in the photographs below. Fill oil into the top drain plug until it starts to come out of the
other drain plug. Replace both plugs BEFORE driving machine. Each track gearbox will
have to be done separately.
When changing oil in tracks,
use EP90 Gear Oil.
Removing filler plug
Track gearbox in correct position to refill
motor with oil.
Removing level plug
36
