Extech Instruments 380193 User Manual

380193-en-GB_V2.6 8/16
10
Resistance
Range accuracy (1kHz & 120Hz) Note
10.000M
±(2.0%rdg + 8d) after open cal*
1.9999M
±(0.5%rdg + 5d) after open cal*
199.99k
±(0.5%rdg + 3d)
19.999k
±(0.5%rdg + 3d)
1.9999k
±(0.5%rdg + 3d)
199.99
±(0.8%rdg + 5d) after short cal
0.020 to 19.999
±(1.2%rdg + 8d) after short cal
*Note: For resistance readings above 1MΩ, series and parallel impedances may affect readings
(especially at 1kHz). This effect is often noticed on decade resistance boxes where the AC
measured value can vary from the DC calibrated value. Use fixed value low inductance resistors
(film or equivalent) for high resistance calibration or certification.
Note: In the 20 range, effective readings must be over 20 counts.
Test Frequency (accuracy) 122.88Hz (±4Hz) and 1kHz (±4Hz)
Display: Dual 4 ½ digit backlit LCD
Overload indication: “OL”
Low battery indication:
Measurement rate: One time per second
Auto-power off: After 10 minutes of inactivity
Operating environment: 0
o
C to 50
o
C (32
o
F to 122
o
F), < 80% RH
Storage environment: -20
o
C to 60
o
C (14
o
F to 140
o
F), < 80% RH, battery removed
Power: 9V battery or optional external 12V-15V @ 50mA (approx.)
Fuse 0.1A/250V fast blow
Dimensions: 19.2x9.1x5.25cm (7.56x3.6x2.1”)
Weight: 365g (12.9oz)
Copyright©2011‐2016FLIRSystems,Inc.
Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform
www.extech.com
