SPECIFICATIONS
Capacitance @ 120Hz
Range Cx accuracy DF accuracy Note
9.999mF ±(5.0% rdg + 5d)
(DF<0.1)
±(10%rdg + 100/Cx + 5d)
(DF<0.1)
after short cal
1999.9μF ±(1.0% rdg + 5d)
(DF<0.1)
±(2%rdg + 100/Cx + 5d)
(DF<0.1)
after short cal
199.99μF ±(0.7% rdg + 3d)
(DF<0.5)
±(0.7%rdg + 100/Cx + 5d)
(DF<0.1)
19.999μF ±(0.7% rdg + 3d)
(DF<0.5)
±(0.7%rdg + 100/Cx + 5d)
(DF<0.1)
1999.9nF ±(0.7% rdg + 3d)
(DF<0.5)
±(0.7%rdg + 100/Cx + 5d)
(DF<0.1)
199.99nF ±(0.7% rdg + 5d)
(DF<0.5)
±(0.7%rdg + 100/Cx + 5d)
(DF<0.5)
after open cal
19.999nF ±(1.0% rdg + 5d)
(DF<0.1)
±(2.0%rdg + 100/Cx + 5d)
(DF<0.1)
after open cal
Capacitance @ 1kHz
Range Cx accuracy DF accuracy Note
999.9μF ±(5.0% rdg + 5d)
(DF<0.1)
±(10%rdg + 100/Cx + 5d)
(DF<0.1)
after short cal
199.99μF ±(1.0% rdg + 3d)
(DF<0.5)
±(2.0%rdg + 100/Cx + 5d)
(DF<0.5)
after short cal
19.999μF ±(0.7% rdg + 3d)
(DF<0.5)
±(0.7%rdg + 100/Cx + 5d)
(DF<0.1)
1999.9nF ±(0.7% rdg + 3d)
(DF<0.5)
±(0.7%rdg + 100/Cx + 5d)
(DF<0.1)
199.99nF ±(0.7% rdg + 5d)
(DF<0.5)
±(0.7%rdg + 100/Cx + 5d)
(DF<0.1)
19.999nF ±(0.7% rdg + 5d)
(DF<0.1)
±(0.7%rdg + 100/Cx + 5d)
(DF<0.1)
after open cal
1999.9pF ±(1.0% rdg + 5d)
(DF<0.1)
±(2.0%rdg + 100/Cx + 5d)
(DF<0.1)
after open cal
Inductance @ 120Hz
Range Lx accuracy (DF<0.5) DF accuracy (DF<0.5) Note
10000H Not specified Not specified
1999.9H ±(1.0%rdg + Lx/10000 + 5d) ±(2.0%rdg + 100/Lx + 5d) after open cal
199.99H ±(0.7%rdg + Lx/10000 + 5d) ±(1.2%rdg + 100/Lx + 5d)
19.999H ±(0.7%rdg + Lx/10000 + 5d) ±(1.2%rdg + 100/Lx + 5d)
1999.9mH ±(0.7%rdg + Lx/10000 + 5d) ±(1.2%rdg + 100/Lx + 5d)
199.99mH ±(1.0%rdg + Lx/10000 + 5d) ±(3.0%rdg + 100/Lx + 5d) after short cal
19.999mH ±(2.0%rdg + Lx/10000 + 5d) ±(10%rdg + 100/Lx + 5d) after short cal
Inductance @ 1kHz
Range Lx accuracy (DF<0.5) DF accuracy (DF<0.5) Note
1999.9H Not specified Not specified
199.99H ±(1.0%rdg + Lx/10000 + 5d) ±(1.2%rdg + 100/Lx + 5d) after open cal
19.999H ±(0.7%rdg + Lx/10000 + 5d) ±(1.2%rdg + 100/Lx + 5d)
1999.9mH ±(0.7%rdg + Lx/10000 + 5d) ±(1.2%rdg + 100/Lx + 5d)
199.99mH ±(0.7%rdg + Lx/10000 + 5d) ±(1.2%rdg + 100/Lx + 5d)
19.999mH ±(1.2%rdg + Lx/10000 + 5d) ±(5.0%rdg + 100/Lx + 5d) after short cal
1999.9μH ±(2.0%rdg + Lx/10000 + 5d) ±(10%rdg + 100/Lx + 5d) after short cal
Note: Where Lx or Cx is the the C or L reading in the display without range indication.
i.e. For a reading of 18.888, use 18888 as the factor.
