380193-en-GB_V2.6 8/16
2
INTRODUCTION
Congratulations on your purchase of Extech's Model 380193 LCR meter. This meter will accurately
measure capacitors, inductors and resistors using the test frequencies of 120Hz and 1 kHz. The
dual display will simultaneously display the associated quality factor, dissipation or resistance value
using a series or parallel equivalent circuit.
The included RS-232c PC interface feature with Data Acquisition permits the user to capture
readings to a PC for data storage, viewing, printing, and exporting to spreadsheet for graphing and
other data manipulation tasks.
This meter is shipped fully tested and calibrated and, with proper use, will provide years of reliable
service.
International Safety Symbols
!
Caution ! Refer to the explanation in this Manual
Caution ! Risk of electric shock
Earth (Ground)
Safety Precautions
1. Make sure any covers or battery doors are properly closed and secured.
2. Always remove the test leads before replacing the battery or fuses.
3. Inspect the condition of the test leads and the meter itself for any damage before operating the
meter. Repair or replace any damage before use.
4. To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
5. Do not exceed the maximum rated input limits.
6. Always discharge capacitors and remove power from the device under test before performing
Inductance, Capacitance, or Resistance.
7. Remove the battery from the meter if the meter is to be stored for long periods.
