Specifications
Front Panel Specifications (AC sine wave output, bandwidth 1kHz)
Function Range Resolution Accuracy Comment
Voltage 85V to 250V 0.1V ±1% THD < 2%
Frequency 45Hz to 65Hz 0.01Hz ± 0.1 Hz -
Power 10mW to 100W 0.1mW ± 1 % ± 0.05W -
Current 5mA to 0.6A
0.1mA/ 1mA
± 1 % ± 0.5mA
See notes: 1, 2
0.6A to 1.5A ± 1 % ± 5mA
Power Factor PF (0 ~ 1) 0.001PF ± 0.04 -
NOTE 1: The maximum output power is approximately 100VA for duration of 2 minutes; therefore the output current
may be varied according to the voltage value. For example, after setting the voltage to ≧150V, the maximum output
current will be 0.75A.
NOTE 2: The output duration can be longer than 2 minutes if the output is less than 100VA. If the output is less than
25VA then the output can run continuously.
Rear Panel Specifications (Input power is looped through to the REAR output)
(Max. 2000VA/220V, 1100VA/110V, AC Measurement)
Function Range Resolution Accuracy
Power 100mW to 2000W 0.1mW/1mW/
0.01W/0.1W/1W
± 1 % ± 0.5W
Voltage 85V to 250V 0.1V ± 1 %
Current 5mA to 0.6A
0.1mA/
1mA/
0.01A
± 1 % ± 5mA
0.6A to 1.5A ± 1 % ± 50mA
1.5A to 10A ± 1 % ± 0.1A
Power Factor PF (0~1) 0.001PF ± 0.04
Frequency 45Hz to 65Hz 0.01Hz ± 0.1Hz
THD THD (0.0 - 20.0%)
0.1%
± 2%
THD (20.0 – 100%) ±3% of reading ±5%
THD (100 – 999.9%) ±10% of reading ±10%
Harmonics Hn (1 – 10
th
)
0.1mA/ 0.001A/
0.01A
mA: ±1.4% of reading ±5mA
A: ±1.4% of reading ±0.3A
Hn (11 – 20
th
) mA: ±4% of reading ±5mA
A: ±4% of reading ±0.3A
Hn (21 – 50
th
)
Amp range
mA: ±10% of reading ±5mA
A: ±10% of reading ±0.3A
Hn (21 –50
th
)
mA range
mA: ±20% of reading ±5mA
A: ±20% of reading ±0.3A
