Setting the Voltage Output (Front Output - only)
1. Type the desired voltage value and press V.ENTER to confirm. The available voltage range is
85 to 250V.
2. Check that the displayed voltage output settings are as desired on the LCD display.
3. If a typing error is made use the button to clear a digit.
4. Press the STBY/OPER button to enable the power supply output.
5. To change the values of voltage use the button to move the underline cursor to the desired
digit and then use the ▲▼to increase or decrease the value.
Warning: When the unit is placed in STBY mode, the output is 0V;
however the output terminals are still physically connected to
the internal circuit.
Frequency Output (Front Output
– Rear Measurement)
1. Type the desired frequency value and then press the Hz button to confirm. The frequency
range is 45 to 65 Hz.
2. Ensure that the displayed frequency output settings are as desired.
3. If a typing error is made, use the button to clear a digit.
4. Press the STBY/OPER button to enable the power supply output.
5. To change the voltage value, use the button to move the underline cursor to the desired
digit and then use the ▲▼to increase or decrease the value.
Note:
This setting will affect the REAR Output power measurements when frequency is involved.
When monitoring the REAR output power, set the Frequency output setting to that of the incoming
Line voltage.
