Extech Instruments 381676A User Manual

381676A-en-GB_V1.1 08/15
7
ACandDCVOLTAGEMEASUREMENTS
WARNING:RiskofElectrocutionforACMeasurements.Theprobetipsmaynotbelongenough
tocontactthelivepartsinsidesome240Voutletsforappliancesbecausethecontactsare
recesseddeepintheoutlets.Asaresult,thereadingmayshow0voltswhentheoutletactually
hasvoltagepresent.Makesuretheprobetipsaretouchingthemetalcontactsinsidetheoutlet
beforedeterminingthatnovoltageispresent.

CAUTION:DonotmeasureACorDCvoltageifamotoronthecircuitisbeingswitchedONor
OFF.Largesurgesmayoccurthatcandamagethemeter.

WARNING:Topreventelectricshockanddamagetothemeterorpersonalinjury,donot
measurevoltagesthatmayexceed600VDCorACrms.
NOTES:
Beforeconnectingtheprobeandtestleadatlowervoltageranges,thedisplaymayshowerratic
readings.Thisisnormalbecausethemeterishighlysensitive.Onceaconnectionismade,the
truereadingwillbedisplayed.
‘OL’indicatesanover‐rangeconditioninmanualmode.Ahigherrangeshould
thenbeselected.
Inmanualmode,selectthehighestrangefirstifthevaluetobemeasuredisunknownthenlower
therangeasneeded.
TheACmillivoltrangeisonlyavailableinthemanualrangemode.
1. UsetheprobecoverifmakingmeasurementsoncategoryIIIorabove
installations.
2. SetthefunctiondialtotheVposition.
3. UsetheMode(M)buttontoselectACorDC.
4. Inserttheblacktestleadbananaplugintothenegativejackatthebottomofthemeter.
5. TouchtheblacktestprobetiptotheneutralsideofthecircuitforACmeasurementsorto
thepositivesideofthecircuitforDCmeasurements.
6. Touchthepositivetestprobetiptothe“hot”sideofcircuitforACmeasurementsortothe
negativesideofthecircuitforDCmeasurements.
7. Readthevoltageonthe
display.Themeterautomaticallyselectsoptimumrangeortheuser
maymanuallyselectarangebypressingtheRange(R)button.PressandholdtheRange(R)
buttontoreturntotheAUTORangemode.

A
C

DC



