Extech Instruments BR250 User Manual

3 BR200-BR250-KITS_en-GB_v9.1 3/20
Safety
 Do not expose instruments to moisture
 Turn power OFF when instruments are not in use
 Remove the batteries from the Camera controller when cleaning
 Replace all batteries at the same time
Supplied Equipment
1. Camera controller
2. Color TFT monitor
3. AC adaptor for monitor’s rechargeable battery
4. Video cable for connecting additional monitor
5. Accessories (magnet, hook, mirror) BR200/BR250 only
6. Magnetic mount for monitor
7. Flexible cable and camera head
8. Four (4) ‘AA’ batteries for Camera Controller
Note: Micro SD card and adaptor (not shown)

Extech Instruments BR250 Specifications

General

Camera Resolution	640 x 480 pixels
Video Resolution	640 x 480 pixels
Probe Length	1 m
Waterproof Rating	IP67
Memory	SD card (up to 32 GB)
Operating Temperature	0°C to 40°C

Summary

Safety and Supplied Equipment

Safety Precautions

Essential safety guidelines for using the instrument.

Preparation for Use

Powering the Devices

Instructions for installing batteries and charging the monitor.

Connecting the Flexible Cable

Steps to attach the camera cable to the main unit.

Operation and Setup

Basic Operation

How to turn on the camera and monitor and start viewing.

Accessories and Troubleshooting

Monitor Reset Procedure

Steps to troubleshoot monitor power issues by using the reset button.

Settings Menu
