Extech Instruments DL160 User Manual

5 DL160-en-US_V1.6 7/22
Specifications
Display Multi-function LCD
Maximum data points 262,144 (Single channel or 131,072 (dual channel)
Channels dual channel, TRMS AC Voltage or Current
Sample rate 1s to 24h selectable
Data output USB port
Current Clamp Jaw opening 0.5” (12.7mm)
Open input indication "LO" appears on the LCD
(also if measured value is less than 10V/10A)
Low battery indication Empty battery symbol appears on the LCD
Power supply 4 AAA Batteries and 1 CR 3V memory button battery
(CR2032 or equivalent)
Battery life 5 days (approximately)
AC Adaptor 9V, 0.5A
Standards
, CAT III 600V, for inside use, maximum height
2000 meters
Operating Temperature 32 to 122°F (0 to 50°C)
Operating Humidity <70% RH
Storage temperature: -4°F to 140°F (-20°C to 60°C)
Storage Humidity < 80% relative humidity.
Dimensions 4.5 x 2.5 x 1.3” (114 x 63 x 34mm)
Weight 8.7oz. (248g)
Function Range Accuracy
Voltage (40Hz to 1kHz) 10VAC to 600.0VAC ±2.0%±1V
Current (50/60Hz) 10A to 200.0A ±2.0%±1A
