V5.0 5/04 7
Diode Test Test current of 0.3mA maximum, open
circuit voltage 1.5V DC typical
Continuity Check Audible signal will sound if the
resistance is less than 150Ω
(approx.), test current <0.7mA
Temperature Sensor Requires type K thermocouple
IR Spectral response 6 to 16µm
IR Emissivity 0.95 fixed
IR distance ratio 8:1
Input Impedance >7.5MΩ (VDC & VAC)
AC Response True rms
ACV Bandwidth 50Hz to 1kHz
Crest Factor <3:1 at full scale & <6:1 at half scale
Display 4000 count backlit liquid crystal
Overrange indication “OL” is displayed
Auto Power Off 15 minutes (approximately)
Polarity Automatic (no indication for positive);
Minus (-) sign for negative
Measurement Rate 2 times per second, nominal
Low Battery Indication “ ” is displayed if battery voltage
drops below operating voltage
Battery One 9 volt (NEDA 1604) battery
Fuses mA, µA ranges; 0.5A/250V fast blow
A range; 20A/250V ceramic fast blow
Operating Temperature 41ºF to 104ºF (5ºC to 40ºC)
Storage Temperature -4
o
F to 140
o
F (-20
o
C to 60
o
C)
Operating Humidity Max 80% up to 87ºF (31ºC) decreasing
linearly to 50% at 104ºF(40ºC)
Storage Humidity <80%
Operating Altitude 7000ft. (2000meters) maximum.
Weight 0.753lb (342g) (includes holster).
Size 7.36” x 3.2” x 2.0” (187 x 81 x 50mm)
(includes holster)
Safety For indoor use and in accordance with
the requirements for double insulation to
IEC1010-1 (1995): EN61010-1 (1995)
Overvoltage Category III 600V and
Category II 1000V, Pollution Degree 2.
