Extech Instruments MA250

MA250-EU-EN-V3.2-6/11
10
Specifications
Function Range Resolution
Accuracy
(% of reading + digits)
20.00 AAC 0.01A ±(2.5% + 8 digits) AC Current
50/60Hz
200.0 AAC 0.1A ±(2.8% + 8 digits)
4.000 VAC 0.001V
40.00 VAC 0.01V
400.0 VAC 0.1V
±(1.8% + 8 digits)
AC Voltage
50 to 400Hz
600 VAC 1V ±(2.5% + 8 digits)
400.0 mVDC 0.1mV ±(0.8% + 2 digits)
4.000 VDC 0.001V
40.00 VDC 0.01V
400.0 VDC 0.1V
±(1.5% + 2 digits)
DC Voltage
600 VDC 1V ±(2.0% + 2 digits)
400.0Ω 0.1Ω
±(1.0% + 4 digits)
4.000kΩ 0.001kΩ
40.00kΩ 0.01kΩ
400.0kΩ 0.1kΩ
±(1.5% + 2 digits)
4.000MΩ 0.001MΩ
±(2.5% + 3 digits)
Resistance
40.00MΩ 0.01MΩ
±(3.5% + 5 digits)
40.00nF 0.01nF ±(4.0% + 20 digits)
400.0nF 0.1nF
40.00µF 0.01µF
Capacitance
100.0µF 0.1µF
±(3.0% + 5 digits)
10 to 10kHz 0.01Hz ±(1.5% + 2 digits) Frequency
Sensitivity: 15V rms
0.5% to 99.0% 0.1% ±(1.2% + 2 digits) Duty Cycle
Pulse width: 100μs to 100ms, Frequency: 10Hz to 10kHz
-4.0 to 1400°F
-20 to 760°C
0.1° <400°
1° >400°
±(3% + 9°F/5°C)
Temperature
Type K
Specification does not include probe accuracy. Range of supplied probe is -22
to 572°F (-30 to 300°C).
