Extech Instruments MG310 User Manual

12 MG310-en-GB_V1.0 12/15
Note:Accuracyisstatedat73.4
o
F(23
o
C)and40~75%RH.
Note:Accuracyspecificationsconsistoftwoelements:
(%reading)–Thisistheaccuracyofthemeasurementcircuit.
(+digits)–Thisistheaccuracyoftheanalogtodigitalconverter.
Display BacklitLCD(max.reading1999)
Lowbatteryindication Batteryicon
appearswhenbatteriesneedtobereplaced.
Overloadindication Insulationresistancetesting>5.5Gdisplayedwhenthemeterrangehas
beenexceeded.
Rangeselection Automatic
Unitsofmeasureformat Functionsandunitsofmeasureareshownsimultaneously.
Testingcontrols ForInsulationResistancetesting:ManualstartandAutomaticstop.
Testbutton Red
lamponTESTbuttonindicatesthattestisinprogress.
Self‐Test 10MΩ(±1%)
ContinuityCheck Audiblesignalwhenresistanceis<20(approx.).
Battery Six(6)1.5V‘AA’batteries
CurrentConsumption 200mAapprox.withmaximumoutput(10mAundernormalconditions).
OperatingTemperature 0ºCto40ºC(32ºFto104ºF)
Storage
Temperature‐20
o
Cto60
o
C(‐4
o
Fto140
o
F)
OperatingHumidity <85%RH
StorageHumidity <90%RH
OperatingAltitude 2000m(7000ft.)maximum
Weight 0.7kg.(1.5lbs.)
Size 150x100x71mm(6.0x4.0x2.8in.)
Safety Thismeterisintendedfororiginofinstallationuseandprotectedby
doubleinsulationperEN61010‐1
andIEC61010‐12
nd
Edition(2001)to
CategoryIII600V;PollutionDegree2.


Copyright©2015FLIRSystems,Inc.
Allrightsreservedincludingtherightofrepr oductioninwholeorinpartinanyform
www.extech.com
