Extech Instruments RH490 - Meter Components and Display; Physical Controls and Sensor; LCD Display Overview

RH490 V2.0 12/06
3
Meter Description
1. Humidity & Temperature Sensor
2. LCD Display
3. Power ON/OFF button
4. °F/°C/WBT (wet bulb)/Dew Point button
5. Hold/MIN-MAX button
6. %RH, GPP, g/Kg, Backlight button
Note: The battery compartment is located
on the rear of the instrument
Display Description
1. Relative Humidity %
2. Dew Point
3. Wet Bulb
4. °C/°F
5. Temp/WB/DP Display
6. Maximum
7. Minimum
8. Low Battery
9. Hold
10. RH% Display
11. Auto Off
12. Grains per pound
