Page #7 background image
SD700-EU-EN V2.4 07/13
7
Specifications
Display 60 x 50 mm (2.4 x 2.0”) LCD
Measurements Temperature, Relative Humidity, and Barometric Pressure
Memory Card SD memory card, 1 GB to 16 GB
Datalogger Sampling Time 5/10/30/60/120/300/600 seconds or Automatic
Temperature Compensation Automatic
Display update rate Approx. 1 second
Data Output RS 232 Serial Interface
Operating Temperature 0 to 50°C (32 to 122°F)
Operating Humidity Less than 90% RH
Power Supply Six (6) ‘AAA’ Alkaline or heavy duty 1.5 V batteries or
9V AC adaptor
Battery life Dependent on sample rate, for new alkaline batteries and 60 second
sampling time, > one month is typical (fast sample rates will
significantly reduce battery life)
Weight 282 g (0.62 lbs.)
Dimension 132 x 80 x 32mm (5.2 x 3.1 x 1.3”)
Range Resolution Accuracy (of reading)
0.0 to 50.0 °C 0.1°C ± 0.8°C
Temperature
32.0 to 122.0°F 0.1°F ± 1.5°F
70 to 90% 0.1% ± (4% of rdg + 1% RH)
Relative Humidity
10 to 70% 0.1% ± 4% RH
10.0 to 1000.0 hPa 0.1 ± 2 hPa
1000.1 to 1100.0 hPa 0.1 ± 3 hPa
7.5 to 825.0 mmHg 0.1 ± 1.5 mmHg
Barometric Pressure
0.29 to 32.48 inHg 0.01 ± 0.1 inHg
Note: Above specification tests under the environment RF Field Strength less than 3 V/M & frequency
less than 30 MHz only.
All EU users are legally bound by the Battery Ordinance to return all used batteries to
community collection points or wherever batteries / accumulators are sold.
Disposal in household trash or refuse is prohibited.
Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the
end of its lifecycle
Other Battery Safety Reminders
Never dispose of batteries in a fire. Batteries may explode or leak.
Never mix battery types. Always install new batteries of the same type.
Copyright © 2013 FLIR Systems, Inc.
All rights reserved including the right of reproduction in whole or in part in any form
ISO-9001 Certified
www.extech.com
