Extel MULTI PRO - English

CFI EXTEL MULTI PRO - 12/2011
GB1
SUMMARY
1 SAFETY INSTRUCTIONS. ................................................ p.1
2 DESCRIPTION. ................................................................... p.2
3 COMPONENTS .................................................................. p.2
a. Indoor station
b. Roadside panel
4 INSTALLING ....................................................................... p.2
a. Installing of the roadside panel
b. Mounting the handset
c. Installing the transformer
5 WIRING ....................................................................... p.3
a. Connecting the interphone
b. Connection of an electric catch, lock and of a gate motor
c. Connecting an extra indoor station (option CB BUS PRO 2)
d. Power supply connection
e. 3- or 4-family mode activation
6 TECHNICAL SPECIFICATIONS ...................................... p.4
a. Indoor unit
b. Power supply
c. Outdoor unit
7 OPTIONS .................................................................... p.4
8 TECHNICAL ASSISTANCE - GUARANTEE ................ p.5
9 SAFETY INSTRUCTIONS ........................................... p.6
1. SAFETY INSTRUCTIONS
Important :
• Please read the user manual thoroughly before installing or using this product.
• If you install this product for other people, please give the manual or a copy to the end user
Warning :
•
The different elements can only be dismantled by an authorised technician. .
Safety instructions :
•
To safely use this system, it is essential the fitters, users and technicians follow the safety procedures described
in this manual.
• Specific warnings and caution symbols are indicated on the elements if necessary.
