Extel WAVE 2 - KIT CONTENTS; Monitor and Intercom Panel; Included Accessories; MONITOR DESCRIPTION

EXTEL - WAVE 2 - 720321
en - 2
A - KIT CONTENTS
B - DESCRIPTION OF MONITOR
1 Monitor
2 Intercom panel
3 Rechargeable battery
4 Plug
5
Fixing screws for monitor bracket and surface
mounting bracket
1 7" colour screen
2 Microphone
3
Screen off: Intercom panel preview
Menu: left arrow or up arrow
Call in progress: takes a photo
4
During communication: Starts/ends a call
In monitoring mode: initiates communication
Menu: right arrow or down arrow
5
Screen off: Enables touch keys and access
to the time and then the menu by pressing
again
Menu: OK (selection button)
Call in progress: Access the image settings
6
Hexagonal screwdriver 1.5mm
7 Plug-in power supply for the screen
6
In call or monitoring mode: Closing of the
control output S1 S2 of the intercom panel
7
Menu: Back/Exit (back button to parent menu)
8 Loudspeaker
9 Jack connector for powering
10 SD memory card slot (8GB, included)
11
QR code to identify the doorkeeper
12
Antenna
Fig. 1
Fig. 2
C - DESCRIPTION OF THE
INTERCOM PANEL
1 Protective case
2 Camera
3 Loudspeaker
4
Call button and name holder (the transparent
plastic can be peeled back to write on the
label)
5 Microphone
6
Dawn-to-dusk cell capable of detecting
ambient brightness and in infrared LEDs
Fig. 3
7 Transformer power input 5V 1A (not included)
8 Control output
