20-10-03 Torque Values
Nuts, except of counter nuts are mainly stop nuts according
to LN 9348 or self-locking nuts according to AN 363.
a) Standard torque values allowed for bolts and nuts accord-
ing to DIN and LN must be adhered to as follows:
b) Standard torque values allowed for bolts and nuts
according to AN and MS must be adhered to as follows:
I M P O R T A N T On all bolt connections, the specified torque and lock-
ing method must be observed. Do not reuse stop nuts if
they can be run up finger tight!
I
n
c
h
t
h
r
e
a
d
s
i
z
e
T
o
r
q
u
e
v
a
l
u
e
(
N
m
)
(
i
n
.
l
b
s
)
1/4 -28
3,5-4,5 30-40
5/16 -24
6,7-9,5 60-85
3/8 -24
10,7-12,5 95-110
7/16 -20
30,5-33,9 270-300
1/2 -20
32,8-46,3 290-410
9/16 -18
88,1-67,8 480-600
M
e
t
r
i
c
t
h
r
e
a
d
s
i
z
e
T
o
r
q
u
e
v
a
l
u
e
(
N
m
)
(
i
n
.
l
b
s
)
M4
1,8 16
M5
3.9-4.3 35-38
M6
6.2-6.8 55-60
M8
15.2-16.8 144-148
M10
29.5-32.5 261-287
M
1
2
x
1
.
5
51-57 452-504
