CHAPTER 20
PAGE 12
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
20-20-00 ASSEMBLY INSTRUCTION
20-20-01 General
N O T E Make appropriate logbook entry of compliance with this
Assembly Instruction after Container Shipping.
In case of the aircraft is delivered in a container it has to be
assembled on arrival.
For assembly of aircraft main components follow the
instructions as outlined in the Chapter 20-20-02.
These instructions can not replace the skill, craftsmanship
and sound technical knowledge of qualified personnel. In
case of doubt or lack of information, the manufacturer of
the respective component should be contacted for advice.
Unless otherwise specified all bolts and connections should
be torqued as listed in Chapter 20-10-03. At some locations
special torque values considered necessary. Refer to Chap-
ter 20-10-04. The stated direction "Front" and "Rear" are to
be considered in respect of pilot`s seating direction.
20-20-02 Assembly Instruction after Container
Shipping
Complete each step of the assembly procedure in the order
shown below.
1 Check the condition of fastening of the aircraft com-
ponents in the container. Note any damage.
2 Remove the fuselage/engine assembly from the con-
tainer. Prevent the aircraft from nosing over by keep-
ing down the tail.
3 Weight the tail per Chapter 07.
4 Remove the aircraft components out of the container.
Small parts, hardware, spinner dome and the wheel
fairings You find in the cockpit.
