CHAPTER 24
PAGE 6
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
24-31-00 MAINTENANCE PRACTICES
I M P O R T A N T If replacement of wiring passing the firewall is neces-
sary, renew the sealing of the bushing grooves and gaps
at the engine side of the firewall. Use PRC-812 (Prod-
ucts Research & Chemical Corporation, USA) firewall
sealant.
24-31-01 Battery
Removal/Installation
C A U T I O N Ensure the master switch is in Off-position.
1 Remove the engine cowlings as per Chapter 51-00-01.
2 Disconnect the electrical wiring.
3 Remove the 4 attachment nuts (LN9348-06) and the
top attachment frame.
4 Lift the battery out of its bottom frame and then re-
move.
5 Install in reverse sequence of removal.
24-31-02 Master Relay
Removal/Installation
C A U T I O N Ensure the master switch is in Off-position.
1 Remove the upper engine cowling and main fuselage
cover as per Chapter 51-00-01.
2 Disconnect electrical wiring.
3 Remove the DIN933 M5x12 attachment bolts, the
DIN9021 M5x20 washers and the LN9348-05 stopnuts.
