CHAPTER 03
PAGE 3
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
03-00-00 GENERAL
This chapter shows a short survey of the particular systems.
A more detailed description of the systems you find in the
respective chapters (see: CONTENTS).
The Extra 200 (refer to Figure 1) is designed as a light
weight, single-engine, two seat, low-wing monoplane us-
ing composite and steel materials. It has a fixed main
landing gear and a tail wheel unit with full-swivel capabil-
ity.
View EXTRA 200
Figure 1
