Extra 200 - Vertical Stabilizer Maintenance

EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 55
PAGE 10
PAGE DATE: 1. July 1996
55-21-02 Vertical Stabilizer
Removal
1 Remove the tail fairing and the tail cone access panel
per Chapter 51-00-01.
2 Remove the rudder per Chapter 27-21-01.
3 Remove the bottom hinge bracket assembly per Chap-
ter 27-21-02.
4 Remove the two LN 9348-10 stop nuts (2, Figure 4)
and DIN 125 M10 washers of the front main bolts.
5 Remove the rear LN 9037-10042 main bolt (3) with
the DIN 125 M10 washers and the LN 9348-10 stop
nut.
C A U T I O N Do not put the fin too far backward, the antenna could
be damaged.
6 Put the fin backward and lift the fin over the antenna.
Installation
1 Put the vertical stabilizer leading edge over the antenna.
C A U T I O N Do not put the fin too far backward, the antenna could
be damaged.
2 Slide the auxiliary spar attachment sheet (1, Figure 6)
of the vertical stabilizer from the rear over the
preinstalled horizontal stabilizer front spar bolts and
install the DIN 125 M10 washers and LN 9348-10 stop
nuts (2).
3 Insert the LN 9037-10042 bolt (3) to the main spar
from rear to front. Use LN 9348-10 stop nuts and DIN
125 M10 washers.
4 Install the bottom hinge bracket to the tail per Chapter
27-21-02.
5 Reinstall the tail fairing, the tail side skins and the tail
cone access panel per Chapter 51-00-01.
MAINTENANCE PRACTICES
