EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 57
PAGE 8
PAGE DATE: 1. July 1996
12 Secure main spar tubular bolts with LN 9038-08020K
bolts (2), DIN912 M8 and aluminum 30x11x4 wash-
ers. Torque security bolts for fastening and subse-
quently safety wire.
13 Fasten auxiliary spar attachment bolts.
14 Reinstall the right front canopy hinge.
15 Reinstall the fuel selector valve control rod per Chap-
ter 28.
16 Reinstall prop vernier control handle and tie-raps for
fastening the cable.
17 Unfix throttle lever and control sticks.
18 Install short aileron push pull rods per Ch. 27-01-01.
19 Perform an aileron rigging per Chapter 27-11-02.
20 Connect fuel system (tubes and vent lines), pitot/static
system, stall warner, navigation/strobe light wires (if
installed), ground bonding leads and fuel indicator
wires with prefitted plugs per respective Chapters.
21 Reinstall breather line, engine cowlings, main fuselage
cover and canopy.
MAINTENANCE PRACTICES
Wing
PAGE DATE: 15. December 1999
