CHAPTER 07
PAGE 5
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
07-20-02 Shoring the Tail
Refer to Figure 3.
1 Secure the main wheels with wheel chocks.
2 Make available two ca. 2.5 feet high, ca. 1 foot wide
and ca. 3 feet long supports.
3 Cushion the supports.
C A U T I O N Don´t handle the elevator when lifting the tail.
W A R N I N G Do not lift the tail higher than necessary for support-
ing. The aircraft may tilt onto the nose.
4 Lift the tail some centimeters by handling carefully
the horizontal fins and put the cushioned supports un-
der each side of the horizontal stabilizer.
Shoring the Tail
Figure 3
SHORING
