CHAPTER 08
PAGE 7
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
08-20-00 LEVELING
N O T E Level the aircraft only on even floor and in closed halls
(wind protected).
1 Secure each main wheel with two wheel chocks.
W A R N I N G Do not lift tail wheel higher than necessary for leveling.
The aircraft may tilt onto the nose.
C A U T I O N Prior to levelling, ensure aircraft is clear of obstruc-
tions.
2 Lift tail and put the jack (height: ~90 cm (~3 ft)) under
the tail wheel, which has to be in the rearmost posi-
tion.
3 Level the aircraft to its horizontal reference line using
a spirit level (2), which is to put under the bolts of the
rear main fuselage cover (1, Figure 1). Adjust pitch by
changing the jack height.
Leveling
Figure 1
