ENGLISH
2ND TIME SLOT SWITCHON
At this point, the second time slot must be programmed.
The sequence to be followed is the same and is repeated as per the 1ST TIME SLOT SWITCHON.
On this occasion simply enter the time, for example start at 15:00 and Stop at 22:00 and to activate the days Saturday and
Sunday by setting them at "ON".
CONTROLS PROCEDURE:
Press key 5 and SET CLOCK will appear.
Press key 2 until
ENABLE CHRONO
appears
- Enable the chrono
- Enable slot 1 and 2.
- Press key 1 to exit
SET
CLOCK
ENABLE
CHRONO
1ST TIME SLOT SWITCHOFF
Using keys 2 - 3, enter the time “12:00”,
which corresponds to the switch-o
time of the 1st time period. The STOP
PRG1 text will appear followed by the
time set.
To conrm and continue programming,
press button 5. Press button 4 to go
back to the previous parameter.
STOP
PRG1
12:00
* Where “ENABLE CHRONO” is not
present in the menu, enabling is done
directly in SET CHRONO.
Press key 2 and SET CHRONO will
appear.
CHRONO
SETTING
ENABLING THE 1ST TIME SLOT DAYS
To do this, use keys 3 and 5 in the
following way:
Key 5 - allows to scroll the various
days, the scrolling text with the day of
the week, followed by OFF.
Use key 3 to enable-disable (ON/OFF)
all days.
MONDAY..
PRG1
ONOFF
Press key 5 to conrm and continue
programming.
The scrolling text
START PRG1 OFF will appear.
START
PRG1
OFF
Press key 5 to conrm and continue
programming.
The text START PRG2 OFF will appear.
START
PRG2
ONOFF
1ST TIME SLOT SWITCHON
Using keys 2 - 3, enter the time “08:00”,
which corresponds to the switch-on
time of the 1st time span. The START
PRG1 text will appear followed by the
time set.
To conrm and continue programming,
press button 5. Press button 4 to go
back to the previous parameter.
START
PRG1
08:00
2ND TIME SLOT SWITCHON
At this point, the second time slot must
be programmed.
The sequence to be followed is the
same and is repeated as per the 1ST
TIME SLOT SWITCHON.
START
PRG2
15:00
J
WHEN THE WEEKLY PROGRAMMER IS ACTIVE, A BOX OF THE RELATIVE ICON WILL APPEAR ON THE
CONTROL BOARD.
PROGRAMMING EXAMPLE
Let's suppose that the weekly programmer function is to be used and the 2 time slots are to be used in the following way:
- 1st time slot: from 08:00 to 12:00 every day of the week, with room temperature at 19°C, excluding Saturday and
Sunday
- 2nd time slot: from 15:00 to 22:00 only on Saturday and Sunday, with room temperature at 21°C
23
