USER PARAMETERS
32
Chapter 10
USER PARAMETERS
USER PARAMETERS
WEEKLY PROGRAMMER
Display D1 Display D2 Function
o 0Act./Deact. Weekly programmer
00:00 1 Time 1st switch-on
00:00 2 Time 1st switch-o
o 13Consents for 1st switch on/o for various days
00 4 Installer parameter
00:00 5 Time 2nd switch-on
00:00 6 Time 2nd switch-o
o 17Consents for 2nd switch on/o for various days
00:00 8 Time 3rd switch-on
00:00 9 Time 3rd switch-o
o 1AConsents for 3rd switch on/o for various days
PELLET FEED ADJUSTMENT
Display D1 Display D2 Function
00 F % pellet feed adjustment
WEEKLY PROGRAMMER
The weekly programmer allows to program 3 time spans within a day to use every day of the week. The
ignition and switch-o times must be within the arc of one day, from 0 to 24 and not over several days:
E.g. switch-on 07:00 / switch-o 18:00 OK
switch-on 22:00:00 / switch-o 05:00:00 ERROR
First of all the current date and time must be set using the “current date and time adjustment” sequence
to give a reference to the function itself.
To access programming press 3, hold it down and press 5 and then release both keys together. Shift
using button 5 until “CHRONO” appears on display D1.
The table below gives all weekly programmer parameters.
Parameter
Function
Keys
adjustment
Value
Key
con rmation
Display D2 Display D1
ON/OFF Act./Deact. weekly programmer 2 o 3 CRONO 5
UT 1 Time 1st switch-on 2 o 3 OFF or from 00:00 to 23:50 5
UT 2 Time 1st switch-o 2 o 3 OFF or from 00:00 to 23:50 5
UT 3
Consents for 1st switch on/o for various days
2 o 3 ON/OFF 1, ON/OFF 2, … ON/OFF 7 5
UT 4 Installer parameter 2 o 3 0 5
UT 5 Time 2nd switch-on 2 o 3 OFF or from 00:00 to 23:50 5
UT 6 Time 2nd switch-o 2 o 3 OFF or from 00:00 to 23:50 5
UT 7
Consents for 2nd switch on/o for various days
2 o 3 ON/OFF 1, ON/OFF 2, … ON/OFF 7 5
UT 8 Time 3rd switch-on 2 o 3 OFF or from 00:00 to 23:50 5
UT 9 Time 3rd switch-o 2 o 3 OFF or from 00:00 to 23:50 5
UT A
Consents for 3rd switch on/o for various days
2 o 3 ON/OFF 1, ON/OFF 2, … ON/OFF 7 1
