Value
Weight kg 159
Height mm 955
Width mm 667
Depth mm 671
Flue gas exhaust pipe diameter mm 80
Air extraction pipe diameter mm 50
Max. overall thermal power kW 16
Max. useful thermal power kW 12.5
- output air power kW 1.0
- output water power kW 11.5
Min. useful thermal power kW 3.5
- output air power kW 0.5
- output water power kW 3.0
Min. hourly fuel consumption kg/h
3.2
Tank capacity kg ~ 30
Recommended chimney draught Pa ~ 10
Chimney draught at max useful power Pa 12
Chimney draught at min useful power Pa 10
Rated electrical power W 310
Rated voltage Vac 230
Rated frequency Hz 50
Water inlet/outlet pipe diameter “ 3/4
Automatic discharge pipe diameter “ -
Pump head m 4
Max accepted working water power bar 1.5
CO measured at max useful power % 0.024
CO measured at min useful power % 0.033
Efficiency at max useful power % 80.8
Efficiency at min useful power % 91.5
Exhaust gas temp. at max useful power °C 214
Exhaust gas temp. at min useful power °C 76.8
Mass of gases emitted at max useful power
g/s 15.17
Mass of gases emitted at min useful power
g/s 6.38
Tests carried out using wooden pellets as fuel, with calorific value of 4.9 kW/h/kg.
The data stated above is a reference and not binding. The manufacturer reserves the right to carry
out any modifications in order to improve the performance of the product.
