Mode Data Rate Power Unit
MCS 6 -68 db
MCS 7 -66 db
MCS 8 -63 db
MCS 9 -61 db
MCS 10 -57 db
MCS 11 -54 db
Device Specifications
l Chassis dimensions when mounted diagonally: 11.375” W 11.375” H 2.9” D (289 mm x 289 mm x 74 mm)
l Weight: 4 pounds (1 .8 kilograms)
l Four dual-band internal WiFi antennas and one BLE internal antenna
l Micro USB Console serial port: (9600 bits per second, 8 data bits, parity: none, 1 stop bit, no flow control
l Eth0 Ethernet port: autosensing 10/100/1000Base-T/TXMbps, with 802.3at-compliant PoE
l Eth1 Ethernet port: autosensing 10/100/1000Base-T/TXMbps
Antennas
AP460C:
l 3 integrated single-band 5.1-5.8 GHz omnidirectional antennas
l 4 integrated dual band 2.4-2.5 GHz and 5.1-5.8 GHz omnidirectional antennas
l 1 integrated single band 2.4-2.5 GHz omnidirectional antenna for BLE
AP460S6C:
l 2 Integrated single band, 5.1-5.8 GHz sector antennas
l 4 integrated dual band, 2.4-2.5 GHz and 5.1-5.8 GHz sector antennas
l 1 integrated single band, 2.4-2.5 GHz omnidirectional antennas for BLE
AP460S12C:
l 2 Integrated single band, 5.1-5.8 GHz sector antennas
l 4 Integrated dual band, 2.4-2.5 GHz and 5.1-5.8 GHz sector antennas
l 1 Integrated single band, 2.4-2.5 GHz omnidirectional antennas for BLE
Antenna Gain
AP460C:
Software Mode
2x2 Rado
WiFi0
4x4 Radio
WiFi1
Scanner
WiFi2
IoT Radio Azimuth Beamwidth
Elevation Beam-
width
Dual band 2.4 GHz 3.24 dBi 5 GHz 4.21 dBi
2.4 GHz 3.74 dBi/
5 GHz 3.42 dBi
3.2 dBi 360 150
Dual 5G 5 GHz 3.56 dBi 5 GHz 4.21 dBi
2.4 GHz 3.74 dBi/
5 GHz 3.42 dBi
3,2 dBi 360 150
AP460S6C:
Software
Mode
WiFi0 WiFi1 WiFi2
IoT
Radio
Azimuth Beam-
width
Elevation Beam-
width
Dual band
2.4 Ghz
7.83dBi
5 Ghz
8.06dBi
2.4 Ghz 7.59dBi/ 5 Ghz
7.63dBi
7.9 dBi 60 60
Dual 5G 5 GHz 3.56 dBi
5 GHz 4.21
dBi
2.4 GHz 3.74 dBi/
5 GHz 3.42 dBi
7.9 dBi 60 60
