Mount the AP460C, AP460S6C, or AP460S12C horizontally or vertically on a pole using the built-in brackets on the hardware, or on a solidflat sur-
face using an accessory bracket (see "Accessories "). These devices can be installedin even the most extreme outdoor environments. The fol-
lowing sections describe the installation process.
Before youinstall the device, make sure that you have all the materials and tools necessary, and familiarize yourself with the safety and site haz-
ard warnings.
For best performance, deploy devices in relatively open areas at least 100' (30.5 m) apart from each other.
Required Tools
To install your device horizontally or vertically on a pole, you will need the following items:
l Two hose clamps that accommodate the diameter of the pole to which youare mounting the device.
l A slotted screwdriver to tighten the hose clamps.
Installation Methods
Install the Device on a Vertical or Horizontal Pole
Use the following steps to install the device on avertical or horizontal pole.
1. Threadtwo hose straps of the correct diameter for the pole through the slots in on the back of the device and around the pole. Hose straps
should be 1/2" (12 or 13 mm) wide and made of stainless steel.
2. While holding the device against the pole, use a slotted screwdriver to tighten first the top and then the bottom hose strap screws to a min-
imum torque of at least 14 inch-pounds until the device is secure. Make sure that the LANglands are facing down (earth) to eliminate the
chance of water entering the chassis. Ifyouare installing the device to sit on top of a horizontal pole, make sure the top of the device faces
up (sky) with the LANglands are protected by the top.
