Table 10: LEDs for Data Ports (1-48)
Port Configuration Color/State Meaning
10/25 Gb Steady green Port OK
Blinking green Port transmitting or receiving
Slow blinking green Port disabled by software
O No link/Fault
Table 11: LEDs for Data Ports (49-54)
Port Configuration Color/State Meaning
100 Gb
or 4x25 Gb
Steady green Port OK
Blinking green Port transmitting or receiving
Slow blinking green Port disabled by software
O No link/Fault
40 Gb
or 4x10 Gb
Steady green Port OK
Blinking green Port transmitting or receiving
Slow blinking green Port disabled by software
O No link/Fault
VSP 7400 Series Front Panel System LEDs
Table 12: VSP 7432CQ Front Panel System LEDs
Label or Type Color/State Meaning
PSU1,PSU2
(Power Supplies)
Steady green PSU is installed and providing power
Steady amber PSU is installed but input power is disconnected or
unit fault detected
O PSU is not installed
FAN Steady green All fans operating normally
Steady amber A fan has been removed or fault detected
O No power to fan modules
SYS
(System)
Steady green Normal operation; agent software code has been
loaded
Blinking green Loading the agent software code
Steady amber Error encountered while running diagnostic
software
Blinking amber Loading and executing the boot loader or
diagnostic software
O Unit not operational
Monitoring the Switch
VSP 7400 Series Switches: Hardware Installation Guide 62
