Table 12: VSP 7432CQ Front Panel System LEDs (continued)
Label or Type Color/State Meaning
PWR
(Power)
Steady green Normal operation
Blinking green System in reset
O Unit not operational
Table 13: VSP 7400-48Y Front Panel System LEDs
Label or Type Color/State Meaning
PSU1,PSU2
(Power Supplies)
Steady green PSU is installed and providing power
Steady amber PSU is installed but input power is disconnected or
unit fault detected
O PSU is not installed
FAN Steady green All fans operating normally
Steady amber A fan has been removed or fault detected
O No power to fan modules
SYS
(System)
Steady green Normal operation; agent software code has been
loaded
Blinking green Loading the agent software code
Steady amber Error encountered while running diagnostic
software
Blinking amber Loading and executing the boot loader or
diagnostic software
O Unit not operational
PWR
(Power)
Steady green Normal operation
Blinking green System in reset
O Unit not operational
Table 14: VSP 7400-48Y Front Panel 100/1G RJ45 Port LEDs
Label or Type Color/State Meaning
OOB Management Port
(Link/Activity)
Steady green Network link
Blinking green Network link and activity
O Link at 10Mbps or no activity
OOB Management Port
(Speed)
Blinking green Port link at 100Mbps
Steady green Port link at 1000Mbps
O Link at 10Mbps or no link
Monitoring the Switch
VSP 7400 Series Switches: Hardware Installation Guide 63
