DTP CrossPoint 84 ā¢ Contents vii
Introduction .............................. 1
About this Guide ........................... 1
About the DTP CrossPoint
Matrix Switchers .......................... 1
DTP Input and Output Signals .. 3
Installation ................................ 4
Rear Panel ..................................... 4
Video Inputs and Outputs ......... 5
Audio Inputs and Outputs ......... 6
Serial and IR Insertion
Connections ............................. 7
Control Connections ................. 7
Switcher Reset .......................... 8
Power ........................................ 8
Additional Connector
Information ............................... 9
Front Panel .................................. 14
Front Panel Operations ......... 15
Creating a Tie .............................. 15
Recalling a Preset ....................... 16
Viewing Ties (and Muting
Outputs) ..................................... 16
Viewing and Adjusting Volume
and Mic Volume ......................... 16
Setting the Front Panel Locks
(Executive Modes) ..................... 17
Selecting Lock Mode 2 or
Toggling Between Mode 2
and Mode 0 ............................ 17
Selecting Lock Mode 2 or
Toggling Between Mode 2
and Mode 1 ............................ 18
Remote Control ..................... 19
Selected SIS Commands ............ 19
Establishing a Network
(Ethernet) Connection ............ 19
Number of Connections .......... 20
Establishing a USB Port
Connection ............................. 20
Host-to-Switcher
Instructions ............................. 20
Common SIS Command
Symbols ................................. 20
SIS Command and Response
Table for Matrix Switcher
Commands ............................. 21
Installing and Starting the
Control Programs ....................... 26
Installing the programs ............ 26
Starting the Product
Conīguration Software .......... 28
Starting the DSP Conīgurator
Program .................................. 29
Accessing the HTML Pages ........ 31
