SW USB Series • Reference Information 29
29
29
Part Numbers and Accessories
Included Parts
Included Part
Replacement
Part Number
SW2 USB 60-952-02
SW4 USB 60-953-02
SW4 USB Plus 60-954-02
3.5 mm, 3-pole captive screw connector with strain relief
(3 for SW2 USB, 2 for SW4 USB and SW4 USB Plus)
100-456-01
3.5 mm, 5-pole captive screw connector with strain relief
(SW4 USB and SW4 USB Plus)
100-457-01
12 VDC power supply with 2-pole captive screw connector attached
IEC power cord
Clear zip ties (3)
Rubber feet, unattached (4)
SW USB Series Setup Guide
Software Products DVD
Optional Accessories
Accessory Part Number
CCR 2BLB Two-Button Contact Closure Remote
With Backlit Buttons (black, white)
70-589-02, -03
CCR 4BLB Two-Button Contact Closure Remote
With Backlit Buttons (black, white)
70-588-02, -03
CCR 204 Four-Button Contact Closure Remote (black) 60-794-02
IR 102 Remote Control Kit 70-224-01
SW2 VGA Series Switcher 60-257-22
SW4 VGA Series Switcher 60-258-22
PS 1210C 12 V, 1 A Desktop Power Supply 70-775-01
2-pole orange captive screw connectors, 10-pack 100-454-01
3-pole blue captive screw connectors, 10-pack 100-456-01
Mounting Options
These mounting kits can be purchased for the SW USB:
Mounting Option Part Number
RSU 129 (9.5" deep 1U universal rack shelf kit) 60-190-01
RSB 129 (9.5" deep 1U basic rack shelf) 60-604-02
RSU 126 (6" deep 1U universal rack) 60-190-10
RSB 126 (6" deep basic rack shelf) 60-604-11
RSF 123 (3.5" deep 1U rack shelf kit) 60-190-20
RSB 123 (3.5" deep 1U rack shelf) 60-604-21
MBU 123 Mini Under-desk Mounting Kit 70-212-01
