Operating Manual
32
4 Technical Data
4.1
iCAM501U
Certification Number ITS09ATEX26868X, IECEx ITS 09.0027X
ATEX Certification
(Units dated before 18
th
July 2013)
II 1 G Ex ia IIB T4 Ga, II 2 G Ex ia IIC T4 Gb, -20°C ≤Ta≤ +60°C
I M1 Ex ia I Ma 0°C ≤Ta≤ +60°C
IECEx Certification
(Units dated before 18
th
July 2013)
II 1 G Ex ia IIB T4 Ga, II 2 G Ex ia IIC T4 Gb, -20°C ≤Ta≤ +60°C
Ex ia I Ma 0°C ≤Ta≤ +60°C
ATEX Certification
(Units dated after 18
th
July 2013)
II 1 G Ex ia IIB T4/T3 Ga, II 2 G Ex ia IIC T4/T3 Gb, -20°C ≤Ta≤ +60°C
I M1 Ex ia I Ma 0°C ≤Ta≤ +60°C
IECEx Certification
(Units dated after 18
th
July 2013)
II 1 G Ex ia IIB T4/T3 Ga, II 2 G Ex ia IIC T4/T3 Gb, -20°C ≤Ta≤ +60°C
Ex ia I Ma 0°C ≤Ta≤ +60°C
FM Certification Intrinsically Safe for Class 1, Division 1, Groups A,B,C,D T4/T3C -20°C≤Ta≤55/50°C
(USA and Canada)
Compliance EMC: EN 55022 1998 class B, EN 55024 1999
LV: EN 60950 2002
FCC: FCC: Class A device, compliance through verification route
Dimensions 132mm x 32mm x 22mm (5.20” x 1.26” x 0.87”)
IP Rating IP65
Operating Temperature Group II -20ºC to +60ºC / Group I 0°C to +60°C
Weight Approx. 200g including batteries
Housing Injection moulded anti-static plastic housing
Relative humidity 95% RH non condensing
Power 2 x Alkaline AA batteries, refer to ATEX/FM Certificate for details on range of approved batteries. Batteries
may not be carried or changed in Group I hazardous areas.
Memory On board 1Gbyte NAND Flash (holds approx. 5,000 JPEG images without any audio recording and
additional 960Kbytes per min for audio)
Image 3.1 Mega-Pixel (2048 x 1536 resolution)
Lens Fixed focus 1/4” format lens in plastic holder
Focal Distance 30 cm to infinity
View Finder Two element optical view finder
Power Modes Operate and auto power-down (after 3 mins)
Battery Life Up to 800 shots without flash and up to 150 shots with flash taken one after the other. 310 shots as per
the CIPA DC-002 standard (mixed mode shots with and without flash)
Note it is very difficult to be precise about exact numbers as there are many factors that can influence this
such as the ambient temperature, how long the camera is powered up, number of voice recordings made
and the number and length of time it is connected to a PC for transferring picture and voice data.
Connectivity USB 1.1 via mini-USB socket for use in the safe area only. Certified for direct connection to a PC without
requiring an external protection barrier
OS Support PTP imaging device in Windows XP/Vista/7 and most versions of Linux.
USB firmware upgrade utility for Windows XP/Vista/7 only.
Flash 4 LED flash giving 131 lux.seconds of energy at 67ms exposure
Audio recording format wav
Image format jpeg
Time and Date Time and date stamping of stored images and filenames
Time and date set via Picture Transfer Protocol (PTP) automatically
