extronics iCAM502 - Icam502

Operating Manual
33
4.2 iCAM502
Certification Number
ITS09ATEX26868X, IECEx ITS 09.0027X
ATEX Certification
II 1 G Ex ia IIB T4
/T3
Ga, II 2 G Ex ia IIC T4
/T3
Gb,
-
20°C
≤Ta≤ +60°C
I M1 Ex ia I Ma 0°C ≤Ta≤ +60°C
IECEx Certification
II 1 G Ex ia IIB T4
/T3
Ga, II 2 G Ex ia IIC T4
/T3
Gb,
-
20°C
≤Ta≤ +60°C
Ex ia I Ma 0°C ≤Ta≤ +60°C
FM Certification
(Units dated after 18
th
July 2013)
Intrinsically Safe for Class 1, Division 1, Groups A,B,C,D T4/T3C
-
20°C
≤Ta≤55/50°C
(USA and Canada)
Compliance
EMC: EN 55022 1998 class B, EN 55024 1999
LV: EN 60950 2002
FCC: FCC: Class A device, compliance through verification route
Dimensions
132mm x
32mm x 22mm (5.20” x 1.26” x 0.87”)
IP Rating
IP65
Operating Temperature
Group II
-
20ºC to +60ºC / Group I 0°C to +60°C
Weight
Approx. 200g including batteries
Housing
Injection moulded anti
-
static plastic housing, supplied with antistatic silicone rubber
boot for additional shock protection
Relative humidity
95% RH non condensing
Power
2 x Alkaline AA batteries, refer to ATEX Certificate for details on range of appro
ved
batteries. Batteries may not be carried or changed in Group I hazardous areas.
Memory
On board 1Gbyte NAND Flash (holds
approx. 5,000 JPEG images without any audio
recording and additional 960Kbytes per min for audio)
3.1 Mega
-
Pixel (2048 x
1536 resolution)
Lens
Autofocus lens, effective focal length 3.39mm, F2.8, 68
o
diagonal field of view
Focal Distance
5cm to infinity
View Finder
Two element optical view finder
Power Modes
Operate and auto power
-
down (after 3 mins)
Battery Life
Up to
600 shots without flash and up to 100 shots with flash taken one after the other. 170
shots as per the CIPA DC-002 standard (mixed mode shots with and without flash)
Note it is very difficult to be precise about exact numbers as there are many factors that can
influence this such as the ambient temperature, how long the camera is powered up,
number of voice recordings made and the number and length of time it is connected to a PC
for transferring picture and voice data.
Connectivity
USB 1.1 via mini
-
USB s
ocket for use in the safe area only. Certified for direct connection to
a PC without requiring an external protection barrier
OS Support
PTP imaging device in Windows XP/Vista/7 and most versions of Linux.
USB firmware upgrade utility for Windows XP/Vista/7 only.
Flash
4 LED flash giving 131 lux.seconds of energy at 67ms exposure
Audio recording format
wav
Image format
jpeg
Time and Date
Time and date stamping of stored images and filenames
Time and date set via Picture Transfer Protocol (PTP) automatically
