16
input A. Resolution is selected using the GATE TIME.
e. TOTAL A. : When this mode is selected, the unit counts cycles of the input A
signal and continuously displays that count.
f. RPM A. : When this mode is selected, the unit displays the RPM(rotation per
minute) of the input A signal.
POWER SWITCH : Push in the unit ON and push out the unit power OFF.
115V 230V
115V
230V
SN :
VOLTAGE POWER MAX
0.5AF
0.25AF
FUSE
10W
10W
2
54
16
3
FIG 6. FC-7150/FC-7015 REAR PANEL
QUALIFIED PERSONNEL.
TO PREVENT ELECTRIC SHOCK HAZARD AND FIRE,
DISCONNECT POWER SUPPLY BEFORE REPLACING FUSE.
DO NOT REMOVE COVER. REFER SERVICING TO
REPLACE ONLY WITH FUSE OF SAME RATING AND TYPE.
RS−232C
INT STD OUT
EXT STD IN
WARNING
FUSE
230V~, 50Hz/60Hz
36
7
4
FIG 7 . FC-3000 REAR PANEL
