Mapping
To enter mapping mode, select the icon
and press OK. Mapping is only available in
Advanced Mode.
While in mapping mode, you can:
• mappoint,lineandareafeatures,including
exclusion zones
• engageanddisengageEZ−Steer
®
Note: Mapping is disabled if you do not
have good qualityGPS.
Mappedfeaturesaresavedwiththefield.To
seemappedfeatureswhenyoureturntoa
field,reloadthefieldandstartaneweventor
continuewithanexistingevent.
Toconfiguremappingoptions,includingwarning
zone distance, recording position, deleting
features,selectConfiguration / Mapping.
Tomapapointfeature,select
and then one
ofthefollowingicons:
Rock Tree
Weed Generic Point
Tomapalinefeature,select
then:
Generic Line
Tomapanareafeature,select and then one
ofthefollowingicons:
Generic Area Exclusion Zone
Todeletetheclosestfeature,selectthe
delete icon:
Delete
Bydefault,theviewautomatically
switchestotheperspectiveviewwhenyou
enterafield.Tosettheviewsoitswitches
whenyouengageanautosteeringsystem
orformanualviewcontrol,inAdvanced
mode select Configuration / System /
Display / View.
Map Screens
Plan View Perspective View
Nudge
Use the and nudge buttons to correct
forpositiondriftcausedbyGPSsatellite
constellationchangeswhiledrivinginthefield.
Nudgeisalwaysappliedtotheguidanceline
relative to the vehicle heading. The total current
nudge distance appears on the tip bar at the
bottomofthescreen.
Toconfigurethenudgeoptions,inAdvanced
mode, select Configuration / System /
Guidance.
Shift to Here
InAdvancedmode,youcanuseShifttoHere to:
• CorrectforGPSpositiondriftwhen
returningtothefieldforguidance,for
exampleafterpausing
• Offsetallswathsforapplicationsin
subsequent years
Youcansavetheshiftedswaths,whichnudge
doesnotallow.
