OPERATION AND SERVICE INFORMATION
Owner’s Guide
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings.
B
CAPACITIES AND REPLACEMENT PARTS
Steering Assembly - excessive play, loose or missing
hardware
3333
Tie Rods - excessive play, bent rods, loose or missing
hardware
3333
Rear Axle - fluid level, oil leakage, noise, loose or
missing hardware
3333
Rear Axle - drain & replace fluid R
Rear Suspension - shock oil leakage, worn bushings,
loose or missing hardware
333
Front Suspension - strut oil leakage, excessive play in
hubs or kingpins, worn bushings, loose or missing
hardware
3333
Front Wheel Alignment - unusual tire wear C&A C&A C&A
Fuel Level
333
333
Fuel System - leaks at tank, cap, system lines for
cracks/deterioration, filters, pump
333
Fuel Filter R
Spark Plug R
Throttle/Governor Linkage - operation & governed
speed
333
Air Filter Element - check & replace as necessary
33
Drive Belt - cracks, frayed, excessive wear
33
REMARKS
before each use
DAILY
WEEKLY
20 rnds/20 hrs
100 miles/160 kms
MONTHLY
60 rnds/60 hrs
300 miles/500 kms
QUARTERLY
125 rnds/125 hrs
600miles/1000 kms
SEMI-ANNUAL
250 rnds/250 hrs
1200miles/2000 kms
ANNUAL
5 YEARS
PAGE
Fig. 19
**Initial oil change after 8 hours of run time.
FLUID QUANTITY
Fuel Tank
6.0 gal (22.5 liters) 87
Octane minimum
Engine Oil 1.25 L (1.3 qt.)
Rear Axle Lubricant Oil SAE 30 1.5 L. (51 oz.)
Fig. 20 Capacities
ITEM PART NUMBER
Oil Filter E-Z-GO P/N 607454
Air Filter E-Z-GO P/N 28463G01
Spark Plug NGK BPR2ES (E-Z-GO P/N 607462)
Starter/Gen. Belt E-Z-GO P/N 606138
Clutch Belt E-Z-GO P/N 606136
Fuse ATC 10A (E-Z-GO P/N 35212G07)
Headlight Bulb 894 (E-Z-GO P/N 74004G01)
Turn Signal Bulb 912-NA (E-Z-GO P/N 74005G01)
Tail Light Bulb 2057 (E-Z-GO P/N 604311)
Fig. 21 Replacement Parts
