Ezviz C1C User Manual

4
Setup
Step 1 Power-on
Plug the power cable into the camera and to the power adapter
and then into a power outlet, as shown in the figure below.
Power Outlet
Power Cable
Step 2 Camera Setup
1. Create a user account
-
Connect your mobile phone to Wi-Fi.
-
Download and install the EZVIZ app by searching “EZVIZ” in
App Store or Google Play
TM
.
-
Launch the app and register for an EZVIZ user account
following the start-up wizard.
2. Add a camera to EZVIZ
-
Log in the EZVIZ app.
-
From the EZVIZ app Home screen, tap “+” on the upper-right
hand corner to go to the scan QR code interface.

Ezviz C1C Specifications

General

Type	IP security camera
Antenna type	Internal
Certification	FCC / CE / UL / REACH / WEEE
Day/night mode	Yes
Operating frequency	2.4 - 2.4835 MHz
Placement supported	Indoor
Connectivity technology	Wireless
Form factor	Spherical
Mounting type	Ceiling/Wall/Desk
Product color	Black, White
Camera pan control	-
Minimum illumination	- lx
Sensor type	CMOS
Optical sensor size	1/2.9 \
Digital zoom	8 x
Lens diameter	2.8 mm
LED type	IR
Night vision distance	12 m
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264
Supported graphics resolutions	1920 x 1080 (HD 1080)
Audio system	2-way
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	72.2 Mbit/s
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
DC output voltage	5
Power source type	USB
Power consumption (max)	4 W
Number of cameras	1
Sustainability certificates	RoHS
Operating temperature (T-T)	10 - 45 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Width	64 mm
Height	103 mm
Weight	96 g
Package depth	79 mm
Package width	123 mm
Package height	125.5 mm
